Rexroth Pressure Switch HED8

HED8.pdf

Download PDF • 626KB

The Rexroth pressure switch HED8 is a mechanical hydraulic pressure switch used to monitor system pressure and convert it into an electrical switching signal. It is designed for industrial hydraulic applications where accurate pressure detection, safety control, and reliable machine operation are required.

This pressure switch is commonly installed in hydraulic circuits to control machine sequences, trigger alarms, or protect equipment from over-pressure conditions.

How Rexroth Pressure Switch HED8 Works

The HED8 operates on a piston-based sensing principle. When hydraulic pressure reaches the preset value, the internal piston moves and activates a microswitch. This changes the electrical contact state and sends a signal to the control system.

The switching pressure can be adjusted manually, allowing the unit to be set according to specific system requirements.

Key Features

• Mechanical piston-type pressure sensing

• Adjustable pressure setting

• High repeat accuracy

• Stable switching performance

• Rugged metal housing

• Suitable for continuous industrial operation

Pressure Range Capability

The Rexroth pressure switch HED8 series covers a wide range of pressure ratings, making it suitable for low, medium, and high-pressure hydraulic systems used in industrial environments.

Models Under Rexroth Pressure Switch HED8 Series

The HED8 series is available in multiple variants based on pressure range and configuration. Commonly used models include:

• HED 8 OA 11/50

• HED 8 OA 11/100

• HED 8 OA 11/200

• HED 8 OA 11/350

• HED 8 OH1X/100

• HED 8 OH-2X/200

• HED 8 OP 20/630

These models differ mainly by pressure range and application suitability. Final selection depends on system pressure, operating conditions, and control requirements.

Typical Applications

• Hydraulic power packs

• Machine tools

• Presses and forming machines

• Injection moulding machines

• Industrial automation systems

• Safety and interlock circuits

Benefits of Using Rexroth Pressure Switch HED8

• Reliable pressure monitoring

• Long service life

• Minimal pressure drift

• Easy installation and adjustment

• Proven performance in industrial hydraulics

Industries prefer the HED8 series because it provides consistent switching accuracy and dependable operation in demanding environments.

FAQs – Rexroth Pressure Switch HED8

1. What is the Rexroth pressure switch HED8 used for?

The Rexroth pressure switch HED8 is used to monitor hydraulic pressure and provide an electrical signal for control, safety, and automation functions.

2. What pressure ranges are available in the HED8 series?

The HED8 series includes models suitable for pressure ranges such as 50 bar, 100 bar, 200 bar, 350 bar, and up to 630 bar.

3. Is the pressure setting adjustable in HED8 switches?

Yes, the switching pressure can be adjusted manually based on system requirements.

4. In which industries is the Rexroth pressure switch HED8 commonly used?

It is widely used in manufacturing, machine tools, presses, injection moulding, automation systems, and hydraulic power units.

5. Where is the Rexroth pressure switch HED8 dealer in India?

Multitech India is a trusted Rexroth pressure switch HED8 dealer supplying genuine products and technical support across India.

6. Is the Rexroth pressure switch HED8 suitable for continuous operation?

Yes, the HED8 is designed for continuous industrial operation and stable long-term performance.

Conclusion

The Rexroth pressure switch HED8 is a dependable solution for hydraulic pressure monitoring in industrial systems. With multiple model options, wide pressure coverage, and robust construction, the HED8 series is suitable for applications where accuracy, safety, and reliability are critical.
